- General Information
- Manufacturer
- Advantech Co., Ltd
- Manufacturer Website Address
- http://www.advantech.com
- Brand Name
- Advantech
- Product Series
- IPS-D22A60W
- Product Type
- Power Supply
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Efficiency
- 88%
- Protection Type
- Over Voltage
- Short Circuit
- Over Current
- Over Temperature
- Features
- LED indicator
- Reliability
- MTBF
- 500000 Hour
- Power Description
- Input Voltage
- 230 V AC
- 100 V DC
- 375 V DC
- Output Voltage
- 48 V DC
- 56 V DC
- Output Voltage Detail
- 48 V DC @ 1.25 A
- 56 V DC @ 1.25 A
- Output Current
- 1.25 A
- Output Power
- 60 W
- Input Frequency
- 63 Hz
- Environmental Conditions
- Minimum Operating Temperature
- -4°F (-20°C)
- Maximum Operating Temperature
- -94°F (-70°C)
- Physical Characteristics
- Form Factor
- Compact
- DIN Rail Mountable
- Enclosed
- Height
- 3.9"
- Width
- 1.5"
- Depth
- 3.7"
- Weight (Approximate)
- 8 oz
- Miscellaneous
- Certifications & Standards
- IEC60068-2-27, 30G
- IEC60068-2-6
- IEC 62368-1
- UL 62368-1
- EN 62368-1
- GB4943.1
- EN55032 (CISPR32)
- EN61000-3-2,3
- EN61000-6-3
- EN61000-6-4,
- EN61204-3 Class A
- EN61000-4-2,3,4,5,6,8,11
- EN61000-6-2
- EN55035
- CRU
- EN61204-3 Class A, Heavy industry level
- EN60715
- CE
- CB
- CCC
- UKCA
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
